SH75
SH75
This loudspeaker offers the perfect combination of high fidelity with sensitivity in a very compact enclosure. Let the SH75 provide small mains, down fill, front fill, or delay applications for your audio needs. It can also be used with subwoofers to create an amazingly compact system that features a 70-degree x 50-degree coverage pattern.
Product Specifications
Coverage Pattern
70˚ horizontal
50˚ vertical
50˚ vertical
Operating Frequency Range
80 Hz – 24 kHz +/-3dB
58 Hz – >24 kHz -10dB
58 Hz – >24 kHz -10dB
Continuous Output
116 dB SPL
Peak Output
122 dB SPL
Sensitivity
93 dB
(2.83 Volts into
rated Z, at 1 meter)
(2.83 Volts into
rated Z, at 1 meter)
Driver Complement
Low/Mid 2 x 8″
High 1 x 1″
High 1 x 1″
Dimensions
20 x 14.5 x 13 inches
Weight
60 lbs
Rated Impedance
4 Ohms
Power Rating
400 Watts Cont.
1600 Watts Peak
1600 Watts Peak
